USING THE METER

Before you use the meter the first time to make a mea-

surement, follow these steps to confirm correct operation

and to familiarize yourself with the meter’s operation.

1. Press

POWER

to turn on the meter. All the display

elements briefly appear.

2. Set the selector to

3. Press

RANGE

to set the meter to the manual range

selection mode.

(Range Hold) appears on the dis-

play. Press

RANGE

again. The decimal point shifts

each time you press

RANGE

. See “Manually Setting

the Range” on Page 20.

4. Use the selector to switch between the meter’s func-

tions and familiarize yourself with the displays.

(illus showing

all controls)

22-178.fm Page 17 Friday, August 6, 1999 11:38 AM
